ANSI B16.5 18000mm ASTM A789 2205 Duplex Seamless Pipe

    Buy cheap ANSI B16.5 18000mm ASTM A789 2205 Duplex Seamless Pipe from wholesalers

    Buy cheap ANSI B16.5 18000mm ASTM A789 2205 Duplex Seamless Pipe from wholesalers
    • Buy cheap ANSI B16.5 18000mm ASTM A789 2205 Duplex Seamless Pipe from wholesalers
    • Buy cheap ANSI B16.5 18000mm ASTM A789 2205 Duplex Seamless Pipe from wholesalers
    • Buy cheap ANSI B16.5 18000mm ASTM A789 2205 Duplex Seamless Pipe from wholesalers

    ANSI B16.5 18000mm ASTM A789 2205 Duplex Seamless Pipe

    Ask Lasest Price
    Brand Name : TOBO
    Model Number : PIPE TOBO-S32760
    Certification : SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED
    Price : USD Negotiated
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 300 Ton/month
    Delivery Time : 25 work days
    • Product Details
    • Company Profile

    ANSI B16.5 18000mm ASTM A789 2205 Duplex Seamless Pipe

    High Strength Super Duplex Seamless Pipe 2205 / S32205 ASTM A789/A790
    1. SCH5S-SCHXXS

    2.Market:America,Africa,Middle East,Southeast of Asia

    3.Product description:


    Outer diameter

    Φ6-630mm

    wall thickness1-50mm
    SizeCustomized
    Manufacturing processThe steel melt shall be refined with AOD or equivalent

    Chemical composition

    Grade: S32760Standard: UNSW: 0.5-1.0

    Others:

    Cr + 3.3Mo + 16N≥40

    C: ≤0.03Si: ≤1.0Mn: ≤1.0P: ≤0.03S: ≤0.01
    Cr: 24-26Ni: 6.0-8.0Mo: 3.0-4.0N: 0.2-0.3Co: 0.5-1.0

    Maximum length

    18000mm/Customized


    Mechanical properties Tensile strength:

    σb≥750Mpa Elongation: δ≥25%

    Typical working conditions30% dilute sulfuric acid, below 60 ℃, annual corrosion rate <0.1mm
    Manufacture StandardANSI : ANSI B16.5, ANSI B16.47, MSS SP44, ANSI B16.36, ANSI B16.48
    DIN : DIN2527, DIN2566, DIN2573, DIN2576, DIN2641, DIN2642, DIN2655, DIN2656, DIN2627, DIN2628, DIN2629, DIN 2631, DIN2632, DIN2633, DIN2634, DIN2635, DIN2636, DIN2637, DIN2638, DIN2673
    B.S : BS4504 , BS4504, BS1560, BS10
    PackageWooden cases, pallets, nylon bags or according to the customers' requirements
    MOQ1pcs
    Delivery time10-100 days depending on quantity
    Payment termsT/T or Western Union or LC
    ShipmentFCA Tianjin/Shanghai, CFR, CIF, etc
    ApplicationPetroleum/Power/Chemical/Construction/Gas/Metallurgy/Shipbuilding etc
    RemarksOther materials and drawings are available.
